Solar Panel Cable connector MC4 3 in 1 T Branch Parallel Solar PV Connector for Solar System

Product Name: Solar Panel Cable connector MC4 3 in 1 T Branch Parallel Adapter

Model: CNT005

Rated Voltage: TUV 1000V DC / UL 600V DC
Rating Current: 20A-30A
Suitable cable cross sections: 2.5mm2-6.0mm2 / 14AWG-10AWG
Pin dimension: 4.0mm
Proof voltage: DC 8KV(1Min)
Pollution degree: 2
Protection class: Class II
Contact Material: Copper, tin-plated
Contact Resistance: 5mW
Connector Material: PPO
Degree of Protection: IP IP67(IEC 60529)
Withdrawal Force: 50N
Insertion Force: 50N
Temperature: -40-+85C
Flame Class: UL94V – 0
Package includes: 1Pair mc4 parallel connector 3in1 T branch electrical solar 30a 1000v mc4 connector

Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
